CONSTRUCTION OBSERVATION BULLETIN: ASC Pacific 3WH & 3WHF metal deck

Issue:
ASC Pacific 3WH & 3WHF metal deck ASC Pacific stopped producing their 3W and 3WF, 3” deep metal deck
around January 2014 and started producing 3WH and 3WHF deck with a flute width of 3 7/8” instead of 4 3/4”. Although most properties of the deck are similar the reduced flute width raises issues with minimum edge distance/flute width requirements for welded-headed studs, as well as inserts and anchors, which may be installed into the bottom of the deck.

Background:
On several recent Hospital Construction projects in California the ASC Pacific 3WH or 3WHF deck was substituted. The implication of the substitution extends to welded-headed studs, inserts and anchors (including post installed anchors) specified for supporting utilities that would have reduced capacities in the narrower flutes of the deck. ASC Pacific reports that they have gone back to producing the 3W and 3WF deck profile with a 4 3/4” wide bottom flute as well as the new 3WH and 3WHF deck with the 3 7/8” wide bottom flute.

Conclusion:
Where ASC Pacific 3WH or 3WHF deck was received since January 2014 the structural engineer of record should investigate the compatibility of the deck bottom flute width with weldedheaded stud values as well as all anchors and inserts specified. All other section, and allowable stress properties of the deck should also be verified against project requirements. Any changes or substitutions shall be approved as an Amended Construction Document per Title 24, Part 1, Section 7-153. All future projects shall verify compatibility of the deck with proposed welded-headed studs, anchors and inserts.

For additional information or questions please email Gerard K. Zelnik, Regional Compliance Officer, Inspection Services Unit at OSHPD.FDDISU@oshpd.ca.gov.

DSA Bulletin BU 15-01

DSA Bulletin BU 15-01: Requirements for Use of ASC Steel Deck 3WH and 3WHF Metal Deck With Concrete Fill

The Division of the State Architect (DSA) has issued Bulletin BU 15-01: Requirements for Use of ASC Steel Deck 3WH and 3WHF Metal Deck With Concrete Fill (PDF – 138 KB) to clarify the requirements for using ASC Steel Deck 3WH & 3WHF metal deck with concrete fill.

The clarification was necessary because ASC Steel Deck stopped producing their 3W and 3WF, 3″ deep metal deck around January 2014 and started producing 3WH and 3WHF deck with a narrower flute width of 3 7/8″ instead of 4 3/4″ used in the 3W and 3WF profiles. Although most properties of the deck are similar, the reduced lower flute width raises the following issues:

  • Reduced edge distance for steel headed studs used for composite beam design and lateral load shear transfer.
  • Reduced edge distance for post-installed anchors and cast-in-place anchors (inserts) installed in the underside of the deck.

If you have any questions, please contact your regional office.

DGS/RESD INSPECTORS TAKE RCI EXAMS

RCI_testUnder the ongoing agreement between the ACIA and DGS, 20 members of the RESD team have taken their Division II Building exams in Northern and Southern California, following review courses taught by Dennis Dooley and other ACIA/RCI members. Photo shows some of the examinees hard at work in Natomas as testing continues.

JIMMY FOSTER RECEIVES HIS EMERITUS DESIGNATION AT NEVADA CHAPTER MEETING ON JANUARY 14, 2015

Jimmy_FosterJimmy Foster has been an RCI since 1993, holding both a Division I Engineering and Division IV Public Works(I) certifications, and he has been an ACIA member since 1997. In November, 2014, at the 55th Annual ACIA Symposium in Long Beach, Jimmy was awarded an Honorary Lifetime Membership and an Emeritus RCI designation. Since he was unable to be present, he received his award from Chapter President Don Kelnhoffer at the regular Nevada Chapter meeting on January 14, 2015. Jimmy was an employee of Clark County Public Works Department for 25 years, and worked for Nevada By Design for 3 years prior to his retirement. Congratulations, Jimmy!

Anaheim Regional Transportation Intermodal Center Tour

ACIA ARTIC TourMembers of the LA Basin and South Coast Chapters of ACIA get a guided tour of the ARTIC (Anaheim Regional Transportation Intermodal Center), an iconic, LEED Platinum design 67,000 square foot hub that brings together the services of OCTA, Metrolink, Amtrak, Anaheim Resort Transportation (ART), Megabus.com, Greyhound, taxis, bikes, and other public/private transportation providers. The February meeting was hosted by ACIA Member William Davis, RCI, who was the IOR on the project.

Important Notice! Time is Running Out!

DID YOU KNOW THAT: Under SB 854 INDEPENDENT PROJECT INSPECTORS ARE CONSIDERED “CONTRACTORS” and need to register with the DEPARTMENT OF INDUSTRIAL RELATIONS. The deadline for filing is FEBRUARY 28, 2015.

Beginning July 1, 2014, contractors must register and meet requirements using the online application before bidding on public works contracts in California. The application also provides agencies that administer public works programs with a searchable database of qualified contractors. Application and renewal are completed online with a non-refundable fee of $300.00. Read the SB 854 Fact Sheet for a complete list of requirements.
Contractors acquiring a public works contractor registration number should pay any fees and/or penalties if applicable by credit card. With a credit card payment, contractors can expect a registration number within 24 hours. Otherwise, any other form of payment will take up to eight weeks for verification of payment and may impact further fees and/or penalties.

Go to www.dir.ca.gov/Public-Works/PublicWorks.html for Online Application and Instructions for completing the form; or to learn more about contractor registration information and process, view a webinar or slide presentation. You may send an email regarding contractor registration to SB854@dir.ca.gov.

Please see attached SB854 Fact Sheet for more information.

Attention RCI examinees

This document is provided for your convenience. Some of the material may be helpful to you in preparing to take the Contract Administration portion of the RCI Exams. You may want to review the contents, although not all of it directly pertains to the exam. Remember, the Contract Administration portion of the exam is “CLOSED BOOK”, so you are not allowed to use printed materials during the exam.

CSI Project Delivery Practice Guide

Thank you,
Paul Beyl, RCI Committee Chair

ACIA Continues to Provide Educational Services to DGS/RESD in 2015

In continuation of its ongoing contract with DGS, the American Construction Inspectors Association will be presenting its RCI Division II Building Inspector classes to Real Estate Services Department (RESD) inspectors in a 6 week course beginning on Monday, January 12, 2015, in Sacramento. At the conclusion of the training, attendees will take the RCI Examination for their Registered Construction Inspectors Certifications.

RESD inspectors from the Southern California area attended the condensed version of the training at the ACIA Symposium in Long Beach in November, and will be taking their RCI examinations in February.

The ACIA is proud of its tradition of providing educational opportunities for inspectors and construction professionals and welcomes RESD participation in our Registered Construction Inspectors Programs.

For more information, please contact the ACIA office at 626-797-ACIA(2242) or executivedirector@acia.com.
